Automatic Unconfined Compressive Strength Machine
This machine equipped to a 5 kN load cell with a resolution of 2.5 N and a LVDT sensor. A Japanese stepper motor with gear box used in machine and Loading system operate uniformly with the rate of 1.27 mm/min without any vibration.
Product description
Technical Specification:
- 4x16 LCD with backlight indicator
- Gearmotor with uniform loading in output
- 5 kN load cell with a resolution of 2.5 N
- Real time force indicator
- RS232 serial port for PC
- Automatic stop at failure point
- LVDT sensor to measure deformation
- Maximum and real time force indicator
- PLC controlling system
- Automatic overload detection
Model SO 680 SO 683 SO 686
Description Motorized Unconfined Digital Unconfined Automatic Automatic Unconfined Compressive Strength Machine Compressive Strength Machine Compressive Strength Machine
Power Supply 0.6kW, 220V, 50Hz,1ph 0.6kW, 220V, 50Hz,1ph 4.5N.m
Indicator Proving Ring Digital LCD 1x16 backlight Digital LCD 4x16 backlight
Capacity 5kN 5kN 5kN
Resolution 2.5N 2.5N 2.5N
Flowmeter Dial indicator.30mm, Dial indicator.30mm, Digital Displacement Div. 0.01mm Div. 0.01mm Transducer 50mm, Div. 0.01mm
Reporting Software - - Includes Processing and
Report Generation Software with Microsoft Excel
Dim.LxWxH 200x150x600mm 200x150x600mm 430x330x700mm
Weight(Approx.) 25kg 25kg 45kg
Stroke Switches 50mm 50mm 50mm
