Full-hydraulic PE welding 630
Given that polyethylene pipes are manufactured in 6- and 12-meter branches, and screw and O-ring fittings have high installation costs and low strength, PE welding machines were designed and built to speed up the work and enhance the installation quality of pipes and fittings. Our PE welding machines are produced based on ISO 12176-1, DVS 2201.
مشخصات
- Brand Name :
- jingermachine
- Model :
- Full-hydraulic PE welding 630
- Place of Origin :
- Iran
Product description
Full-hydraulic PE welding 630
plastic pipe welding machine Model H315_R630
Use cases: It is used in oil and gas, water and sewer pipelines for special polyethylene pipes PE100, PE80, PE63 with Buttweld.
Profile: welding of polyethylene pipes in 315-355-400-450-500-560-630 mm sizes and the working pressure of 2, 2.5, 3.2, 4, 6, 10 and 16 atm.
Dimensions (1250*1100*970) and weighing 721 kg, weight of rings 235 kg. The required power is 11000 watts.
- Working voltage: ~380V ± 10%, 50Hz/60Hz
- (Total power: 12.2 KW, including planning tool: 1.5 KW, heating plate: 9.2 KW, hydraulic unit motor: 1.5 KW)
- Environment temperature: - 10 °C ~ 45°C
- A hydraulic box (power pack) (dimensions 45 x 50 x 56), equipped with electric steering valve and coupling
- A 3000-watt electric heater with industrial Teflon and temperature setting from 50 to 300 ° C (heater weighs 38 kg)
- A milling unit with a 2-HP three-phase gearbox and tempered steel blade made of SPK (milling unit weight 116 kg)
- Rollers to facilitate guiding the pipe and adjusting it on the clamps
- Steering wheel for easy transport and mobility of the device
- An adapter flange (four-state) configurable in different sizes
- Accessories: Work clothes and gloves, educational CD, welding table and welding certificate
