Sliding table machine320 cm - ariamachine
Manual tilting handy Motor lifting electrical Sliding table system altendorf style vagon Speed of main saw spindle 3000/4000/5000 rpm Dimension of sliding table 3200×45 mm Gross cut capacity 3200 mm Saw blade diameter 300mm Scoring saw blade diameter 120mmMain motor 7.5 hp
مشخصات
- 320cm :
- 125cm
Product description
| Manual tilting | handy |
| Motor lifting | electrical |
| Sliding table system | altendorf style vagon |
| Speed of main saw spindle | 3000/4000/5000 rpm |
| Dimension of sliding table | 3200×45 mm |
| Gross cut capacity | 3200 mm |
| Saw blade diameter | 300mm |
| Scoring saw blade diameter | 120mm |
| Main motor | 7.5 hp |
| Scoring motor | 1.5 hp |
| Back table width | 1250mm |
| Hight of cut | 75mm |
| Speed scoring saw blade | 8000rpm |
| Net weight |
| Manual tilting | handy |
| Motor lifting | electrical |
| Sliding table system | altendorf style vagon |
| Speed of main saw spindle | 3000/4000/5000 rpm |
| Dimension of sliding table | 3800×45 mm |
| Gross cut capacity | 3800 mm |
| Saw blade diameter | 300mm |
| Scoring saw blade diameter | 120mm |
| Main motor | 5.5 kw |
| Scoring motor | 0.75 kw |
| Back table width | 1250mm |
| Height of cut | 75mm |
| Speed scoring saw blade | 8000rpm |
| Net weight | 860 kg |
