NVR security Camera Features : ip base , easy setup , wireless integrated , stand alone , night view , motion detection multy view , store 128G offline , application software

مشخصات

nvr camera :
space security
plug & play :
IP Base

Service description

FeaturesSystem securityAccount, password authority management
Free DDNS                                                                                                                                                                                 Free DDNS, supports dynamic IP.
View by phoneSupport HD pic  IOS, Android mobile view (iOS 4.3、Android OS 2.3 above)
Local Storagesupport up to 128GB MicroSD card ,24-hour loop recording.
Monitor AdvantageSupport PC computer monitoring, smartphone multi-pic view.
PnPPlug & Play,99% penetration rate, Easy to setup: 1. connect the network cable and power adapter, 2.install APP, scan UID code to add camera.  3,Click online camera to view the camera.
Sever clusterUsing Amazon Cloud PnP servier cluster, intelligent application and super stable
UID TechnologyUID scan technology applied, easy to operate, and highly confidential.
Super Client1,4,9,16,25,36, 64,81-channel central management software, no user number limitation , centralized surveillance, remote record and playback, alarm email ect.
SystemOSEmbedded Linux OS
Control protocolONVIF 2.4 protocol, high interoperability
Video codingMulti stream:720P@30fps+VGA@30fps+QVGA@30fps+720P @1fsJPEG capture
Bit RateCBR/VBR, output bit rate range:128~4096kbps
ProcessorHi processor, built in ARM926 @Max. 440MHz and high-speed video co-processor
VideoCompression FormatH.264 baseline profile@levels:3.1/Motion-JPEG
Frame rate30fps/24fps(720p)
Resolution720P(1280*720), VGA, QVGA
Picture AdjustmentContrast, Brightness, Saturation are adjustable.
Sensor1/4 720p Progressive CMOS sensor
Minimum illumination0.8Lux/F1.4(colourful model ),0.3Lux/F1.4(B&W mode)
SNR≥39dB
IR controlIR turned on: night vision view enabled, infrared Ray, ICR auto detect.                                                                            IR turned off: night vision disabled, infrared ray off, ICR stay in day view mode.
Electronic shutter1/50s(1/60s)-1/100, 000s
CMOSsupport AWB, AGC, BLC
 Lens/viewing angle3.6mm@F1.4/56.14?
Night VisionNight visionDual IR-CUT Filter auto switch, 12pcs 850nmΦ5mm LED,10m IR distance
AudioCompression formatADPCM/32kbps
Input1 Channel Line in (3.5mm phone jack) &1 Channel Internal -48dB Microphone
Output1 Channel Line out (3.5mm phone jack)&Internal speaker(8Ω1W)
P/TP/TPan:355°,Tilt:120°
Preset Postionsuppor up to 15 preset postions
Networknetwork interface

10Base-T/100Base-TX Ethernet interface
Network ProtocolTCP/IP,HTTP,TCP,UDP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPnP,RTSP,P2P,onvif etc.
wireless network securityone key wifi stup,don't need network cable .
Online visitorSupport 4 online visitors simutaneoursly
IP addressDynamic IP and static IP address
WIFIWIFI 802.11 b/g/n
Othershousing material engineering plastics
Application environmentIndoor
Rated VoltageDC5±0.3V
Temperature-10~50 °C
Power consumptionrated power:3.5W(IR opening )/maximum power:7W(P/T working )
Package size208*154*137mm (L×W×H)
WeightGross Weight :688g(Note: in kind prevail)
AccessoriesPower adapter, user manual, warranty card, mounting bracket, screws.
AlarmMotion DetectionSupport motion detecting
System RequirementSystem configurationWin/XP,Vista,win7 win8  iPhone iOS4.3,The android version 2.3 or higher
CertificateCertificateISO FCC CE RoHS
