Analog electrostatic powder coating M100
High quality coating , Ergonomic design ,Reduction in the use of powder paint , Proper and complete coating of the corner points , Automatic and manual powder spraying gun connectable , High quality body and parts,Fully Repairable and Replaceable parts ,Less weight , One year warranty
مشخصات
- voltage :
- AC220V
- frequency :
- HZ60 /50
- Working temperature :
- -10° C ~ +50° C
Product description
| Gun | |
| Input Voltage | 15V Max |
| Output Voltage | 100 KV |
| Output Current | 160 μA |
| priority | Negative (-) |
| weight | 420 gr |
| length | 340 mm |
| Gun Frequency | MAX 40 K HZ |
| Pneumatic | |
| Maximum Input Air pressure | 8 Bar |
| Average Input Air pressure | 6 Bar |
| Minimum Input Air pressure | 4 Bar |
| Maximum input Air Moisture | 1,4 g/Nm^3 |
| Maximum Input Air oil | 0,1 ppm |
| Maximum Input Air Consume | 13,2 Nm^3/h/24,5Nm^3/h |
