Balancing Machine for Pulleys - CEMB
Cemb, global manufacturer of universal balancing machines for industrial applications, is also a leader in the manufacturing of special systems, fully automatic and dedicated to the automotive field to be entered directly into production lines, with or without their own movement of rotors.
Product description
VUBK50_UF_M
Balancing machine for pulleys with automatic static unbalance correction obtained by a drilling unit.
The drilling depth is managed by a controlled axis motor.
Approx overall dimensions:
Width: 1700 mm
Depth: 3000 mm
Height: 2000 mm
VUBK50/UF-A/1ST
Automatic balancing system, single station.
- Correction of the static unbalance by a controlled axis drilling unit.
- A linear loader pickups and releases the parts by parallel pneumatic grippers.
Approx overall dimensions
Width: 2520 mm
Depth: 2500 mm
Height: 2200 mm
VUBK30/UF-A/2ST
Automatic two-stations balancing system
- Equipped with 180° double arms loader, measuring/control station, correction station and input conveyors.
- Parts output with automatic correction of the static unbalance obtained by a double controlled axes drilling unit.
Approx overall dimensions
Width: 2000 mm
Depth: 2800 mm
Height: 2200 mm
VUBK50/UF/CN/4ST
Automatic four-stations balancing system.
- Equipped with 90° four-arms rotative loader
- Pickup/release station, measuring station, correction station, control station, input/output conveyors and with automatic correction of the static unbalance obtained by a drilling/milling unit.
Approx overall dimensions:
Width: 2840 mm
Depth: 2900 mm
Height: 2200 mm
