Balancing Machine for Clutches - CEMB
Cemb, global manufacturer of universal balancing machines for industrial applications, is also a leader in the manufacturing of special systems, fully automatic and dedicated to the automotive field to be entered directly into production lines, with or without their own movement of rotors.
Product description
VUBS30/PR
Automatic balancing machine for clutches equipped with riveting press unit.
- The unbalance correction is obtained by manual adding of suitable weight rivets and automatic pressing operation.
Approx overall dimensions:
Width: 2600 mm
Depth: 2100 mm
Height: 2000 mm
VUBK50-UF-A
Balancing machine for clutches with unbalance correction by drilling and/or by contour milling.
- Machine with three axes.
Approx overall dimensions:
Width: 3000 mm
Depth: 2900 mm
Height: 2150 mm
VPUBK100_TO
Balancing machine for clutches.
- Unbalance correction is obtained by milling.
Approx overall dimensions:
Width: 2800 mm
Depth: 2700 mm
Height: 2100 mm
VUBK100-TO
Automatic balancing plant for truck clutches.
- Unbalance correction by milling and drilling, complete with loading and unloading device and marking station.
- The machine is protected by a soundproof cabin with suitable windows to allow for maximum visibility of the working area by the operator.
Approx overall dimensions:
Width: 8000 mm
Depth: 4800 mm
Height: 3500 mm
2VUBK30/R/P
Automatic balancing machine with three stations.
The unbalance correction is obtained by automatic selection and placing of rivets by a robot.
- Pressing operation performed automatically on the specific correction, check spin on 100% of clutches
Approx overall dimensions:
Width: 3800 mm
Depth: 3750 mm
Height: 2200 mm
